ASUS – TUF GAMING B650-PLUS
AMD B650 CHIPSET
ASUS TUF GAMING B650-PLUS TAKES ALL THE ESSENTIAL ELEMENTS OF THE LATEST AM5 SOCKET FOR AMD RYZEN™ DESKTOP PROCESSORS AND COMBINES THEM WITH GAME-READY FEATURES AND PROVEN DURABILITY. ENGINEERED WITH MILITARY-GRADE COMPONENTS, AN UPGRADED POWER SOLUTION AND A COMPREHENSIVE COOLING SYSTEM.
-
AMD SOCKET AM5 FOR AMD RYZEN™ 7000 & 8000 SERIES DESKTOP PROCESSORS
-
4 X DIMM, MAX. 128GB, DDR5
7600+(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC & NON-ECC, UN-BUFFERED MEMORY*
DUAL CHANNEL MEMORY ARCHITECTURE
-
1 X DISPLAYPORT*
1 X HDMI® PORT**
-
AMD RYZEN™ 7000 SERIES DESKTOP PROCESSORS*
1 X PCIE 4.0/3.0 X16 SLOT(S)
AMD RYZEN™ 8000 SERIES DESKTOP PROCESSORS*
1 X PCIE 4.0 X16 SLOT (SUPPORTS X8/X4 MODE)**
AMD B650 CHIPSET
1 X PCIE 4.0/3.0 X16 SLOT (SUPPORTS X4 MODE)
2 X PCIE 4.0/3.0 X1 SLOTS
-
TOTAL SUPPORTS 3 X M.2 SLOTS AND 4 X SATA 6GB/S PORTS
AMD RYZEN™ 7000 SERIES DESKTOP PROCESSORS
M.2_1 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 5.0 X4 MODE)
M.2_2 SLOT (KEY M), TYPE 2242/2260/2280/22110 (SUPPORTS PCIE 4.0 X4 MODE)
AMD RYZEN™ 8000 SERIES DESKTOP PROCESSORS
M.2_1 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 4.0 X4 MODE)
M.2_2 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 4.0 X4/X2 MODE)**
AMD B650 CHIPSET
M.2_3 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 4.0 X4 MODE)***
4 X SATA 6GB/S PORTS
