COOLER MASTER MASTERBOX 520 MESH CABINET

MODEL NUMBER

MB520-KGNN-S00, MB520-WGNN-S00

EXTERIOR COLOR

BLACK, WHITE

MATERIALS – EXTERIOR

MESH, STEEL, ABS PLASTIC, TEMPERED GLASS

MATERIALS – LEFT SIDE PANEL

TEMPERED GLASS

DIMENSIONS (L X W X H)

499 X 210 X 498MM (INCL. PROTRUSIONS), 430 X 210 X 479MM (BODY SIZE)

MOTHERBOARD SUPPORT

MINI ITX, MICRO ATX, ATX, SSI CEB, E-ATX*, (*UP TO 12″ X 10.7″ MOTHERBOARDS, MAY IMPACT CABLE MANAGEMENT FEATURE)

EXPANSION SLOTS

7

3.5″ DRIVE BAYS

2

2.5″ DRIVE BAYS

3

I/O PANEL

1X USB 3.2 GEN 1 TYPE-A, 1X USB 3.2 GEN 2 TYPE-C, 1X 3.5MM HEADSET JACK (AUDIO+MIC), 1X RESET/ARGB BUTTON

INCLUDED ACCESSORIES

ARGB FANS HUB

PRE-INSTALLED FANS – FRONT

3X CF120 ARGB

FAN SUPPORT – TOP

3X 120MM, 2X 140MM

FAN SUPPORT – FRONT

3X 120MM, 2X 140MM

FAN SUPPORT – REAR

1X 120MM

RADIATOR SUPPORT – TOP

120MM, 140MM, 240MM, 280MM, 360MM, (RECOMMENDED MAXIMUM THICKNESS -55MM)

RADIATOR SUPPORT – FRONT

120MM, 140MM, 240MM, 280MM, 360MM

RADIATOR SUPPORT – REAR

120MM

CLEARANCE – CPU COOLER

165MM/6.49″

CLEARANCE – PSU

200MM, (RECOMMENDED UP TO 170MM)

CLEARANCE – GFX

410MM/16.1″

DUST FILTERS

BOTTOM, FRONT, TOP

POWER SUPPLY SUPPORT

ATX

WARRANTY

2 YEARS

SERIES

MASTERBOX SERIES

SIZE

MID TOWER
